Top-mounted glass railing system for demanding architectural solutions
The Comenza GlassFit SV-1803 system is a profile-based glass railing solution made of anodized aluminium and designed for top mounting in projects with high structural requirements. Its configuration accommodates installations at the slab edge, facilitating system integration into complex architectural solutions.
Developed for private-use, public-use and crowd-load areas, the SV-1803 provides a robust, safe and versatile solution for projects where resistance and construction integration are key factors.
01. INTEGRATED DESIGN FOR HIGHLY DEMANDING PROJECTS
The SV-1803 features an anodized aluminium profile designed to integrate into architectural solutions with more demanding technical requirements. Its configuration accommodates junctions at the slab edge while maintaining a clean aesthetic consistent with the overall building design. This integration capability makes it particularly suitable for projects where design, resistance and functionality must work together.
02. TESTED SAFETY FOR CROWD-LOAD AREAS
The GlassFit SV-1803 system has been developed to provide a high level of safety in applications subject to high loads. Its performance has been verified through testing to ensure compliance with the technical requirements for private-use, public-use and crowd-load areas. This capability allows it to be installed in environments with high concentrations of people, ensuring stability and protection for users.
03. EFFICIENT INSTALLATION IN COMPLEX TECHNICAL CONFIGURATIONS
The SV-1803 configuration facilitates installation in projects with specific construction requirements while maintaining a precise and controlled installation process. The glass is secured inside the profile without drilling, reducing on-site operations and simplifying handling. This solution helps optimize installation times without compromising safety or the quality of the final result.
Advantages
01. SOLUTION FOR PROJECTS WITH HIGH STRUCTURAL REQUIREMENTS
The SV-1803 is designed for projects where the railing must withstand high loads and ensure reliable performance under demanding conditions. This makes it a suitable solution for public buildings, spaces with high concentrations of people and areas where structural safety is a priority. Its design combines resistance, stability and seamless integration.
02. INTEGRATION AT THE SLAB EDGE
Its top-mounted configuration accommodates installations at the slab edge, facilitating system integration into complex architectural solutions. This feature helps optimize the junction between the railing and the building structure, providing a cleaner and more functional finish. The system therefore adapts to projects with more demanding construction requirements.
03. SUITABLE FOR CROWD-LOAD AREAS
The SV-1803 covers different usage categories, from private spaces to public-use and crowd-load areas. This versatility facilitates its specification in projects with different levels of requirements, providing a single solution for multiple scenarios. Its ability to withstand high loads ensures safety and reliability in intensive-use environments.
04. COMPATIBILITY WITH LED LIGHTING
The GlassFit SV-1803 system allows LED lighting to be integrated into the profile, expanding the design possibilities of the railing. This solution makes it possible to incorporate ambient lighting into the system, enhancing its aesthetic appeal and helping improve visibility in the surrounding area. This option enables the development of glass railing solutions that combine functionality, safety and design.
05. WIDE RANGE OF RAL POWDER-COATED FINISHES
The GlassFit SV-1803 system offers the option of powder coating the profile in a wide range of RAL colours available in the GlassFit catalogue. This makes it possible to adapt the system to the aesthetic requirements of each project, facilitating its integration into different architectural styles and the overall building design.
Safety and regulations
COMENZA railing systems are tested in accordance with Spanish Technical Building Code (CTE) requirements to ensure end-user safety, verifying that they pass static and dynamic load tests. The resistance verification method with variable action established by the CTE is applied, using a partial safety factor of 1.5. This is an essential requirement to ensure maximum safety and regulatory compliance for a railing system.
Installation
Accessories and components
The glazing kit allows LED technology to be integrated to illuminate the railing from the bottom of the glass, creating a distinctive and modern visual effect.
